Loop Vehicle Detector

LD160 Single-Channel Loop Detector

An economical detector developed for reliable barrier control, access management, and everyday vehicle detection projects.

LD160 single-channel loop detector

Flexible Performance at a Practical Cost

The LD160 is designed for projects that need dependable loop detection, easy adjustment, and stable operation without adding unnecessary system complexity. It is a strong fit for general parking and access control applications.

1
Cost-Effective

A practical detector for standard parking and access projects.

2
Easy Adjustment

Field settings allow the detector to adapt to different environments.

3
Stable Operation

Self-tuning helps maintain reliable performance over time.

4
Quick Installation

11-pin rear connection supports straightforward panel integration.

Key Features

  • Economical single-channel detector for parking and access applications.
  • Adjustable operation for different site environments with reduced false detection.
  • Four selectable loop frequencies (20~80KHz) to eliminate crosstalk.
  • Automatic return to normal operation after intermittent or self-healed loop faults.
  • Self-tuning and complete environmental tracking.
  • No warm-up required.
  • Two-color LED status indication for detect, power, and loop fault.
  • 11-pin Amphenol rear connector and ABS housing.

Typical Applications

  • Parking barrier control
  • Vehicle access control

Output Configuration

Output A is a presence output with programmable extension from 0 to 30 seconds through external DIP switches.

Output B is programmable through external DIP switches for presence, pulse on entry, pulse on exit, or fail-safe output.

Technical Specifications

Detector TypeSingle-channel inductive loop vehicle detector
ApplicationsParking barrier control and vehicle access control
Loop Frequency20~80kHz, 4 selectable frequencies
TuningAutomatic self-tuning with environmental tracking
Warm-Up TimeNone required
Status IndicationTwo-color LED for detect, power, and loop fault
Output APresence output with programmable extension from 0 to 30 seconds
Output BPresence, pulse on entry, pulse on exit, or fail-safe output
Delay Function2-second delay available through external DIP switch setting
Connector11-pin Amphenol rear connector
Housing MaterialABS plastic
OriginMade in Taiwan
